Solar Charge Controllers

Solar Charge Controllers
Solar Charge Controllers
Send Inquiry
Product Code : 06
Product Description

We are a prominent manufacturer, supplier and exporter of a wide array of Solar Charge Controllers. The offered devices are used in various industrial and residential applications. These are designed to control and regulate the current and voltage coming from the solar panels. High-end components and updated technology are used to design and develop these controllers under the guidance of professionals. Offered Solar Charge Controllers are meticulously checked on varied parameters of quality to ensure their optimum performance, cost-effectiveness and longer service life.

Main Functional Features:

  • MPPT controllers offer a potential increase in charging efficiency up to 30% (Maximizes energy harvest)
  • These controllers also offer the potential ability to have an array with higher input voltage than the battery bank
  • You can get sizes up to 80 Amps
  • MPPT controller warranties are typically longer than PWM units
  • MPPT offer great flexibility for system growth
  • Longer Battery life
  • Extensive electronic Protections
  • Fully adjustable and highly reliable
  • MCU based buck converter 12/24Volt 20/40A.
  • MPPT Technology, efficiency improved by more than 20%.
  • First in its class LCD with Power and Energy measurement.
  • Menu settable configuration using 2x16 LCD and 3 push buttons.
  • Menu settable Battery voltage, battery current , Float voltage and Float current.
  • Three stage Charging.
  • Over voltage/Over current protection.
  • Optional relays to control Mains charger and Inverter.
  • Lower System Cost


Product Series

GEESYS - M122448

Battery Voltage

12V; 24V; 48V;

Max. Efficiency

> 98%

Own Power Consumption

< 30mA

Rated Charging Current

10A; 20A; 30A; 40A; 50A; 60A;

Rated Load Current

10A; 20A; 30A; 40A; 50A; 60A;

Voltage Drop of Charge Circuit

< 0.40V

Voltage Drop of Load Circuit

< 0.35V

Equalization Charge Voltage

(Used only when battery is deep discharged)

Buck Charge Voltage


Float Charge Voltage


Temperature Compensation


Control Mode


Permitted Operation
Temperature Range

-20oC ~+55oC

Dimensions L x B x H

in mm


  • Boat, RV and off-the-grid home battery storage systems
  • AC Home Lighting System
  • DC Home Lighting System
